- Size: Thickness: Minimum 0.8mm profile; 8-20um
- Place of Origin: shandong
- Brand Name: HR
- Model Number: t slot aluminum profile
- Weight: 1000.000 kg
Inch (Fractional) Extrusion
There are six 10 Series extrusions
1" x 1" [TS 10-10]
1" x 1" QR (quarter round) [TS 10-10QR]
1" x 2" [TS 10-20]
1" x 3" [TS 10-30]
2” x 2” [TS 20-20]
2” x 4” [TS 20-40]
The 10 Series TSLOTS have .255" slot widths and are modular to each other. The 10 Series T-Slot design has an inside radius of .125 inches to make sliding drop-in T-Nuts easier.
There are eight 15 Series extrusions
1.5" x 1.5" [TS 15-15]
1.5" x 1.5" L (light weight) [TS 15-15L]
1.5" x 1.5" QR (quarter round) [TS 15-15QR]
1.5" x 3" [TS 15-30]
1.5" x 3" L (light weight) [TS 15-30L]
1.5" x 4.5" [TS 15-45]
3" x 3" [TS 30-30]
3" x 6" [TS 30-60]
The 15 Series TSLOTS have .322" slot widths and are modular to each other. The 15 Series T-Slot design has an inside radius of .187 inches to make sliding drop-in T-Nuts easier.
Metric Extrusion
There are six 25mm extrusion shapes:
25mm x 25mm [TS 25-25M]
25mm x 25mm QR (quarter round) [TS 25-25QRM]
25mm x 50mm [TS 25-50M]
25mm x 75mm [TS 25-75M]
50mm x 50mm [TS 50-50M]
50mm x 100mm [TS 50-100M]
There are seven 40mm extrusion shapes:
40mm x 40mm [TS 40-40M]
40mm x 40mmL (light weight) [TS 40-40LM]
40mm x 40mmVL (very light weight) [TS 40-40VLM]
40mm x 80mm [TS 40-80M]
40mm x 80mmL (light weight) [TS 40-80LM]
40mm x 80mmVL (very light weight) [TS 40-80VLM]
80mm x 80mm [TS 80-80M]
Order Detailed:
Dimensions | Max section: 250*250mm; Max length: 6.8 Meters |
Trade Term | FOB, CIF |
MOQ | 1 Ton |
Drawings | Received, or provided by our engineers |
Dies | In-house fabricated (require 7-12 days) |
Working/swevice procedure | Die designing → Die making → Smelting & Alloying → Extruding → Cutting → CNC → Drilling → Tapping → Surface treatment → Assembling → Packing → Shipping → After sales service |
Delivery time | Die making:7days Smaples finished:12days Production time:12-15days |
Payment terms: | T/T,L/C |
Shipping | We have good relationship with shipping company,therefore we can help you to save some shipping cost. Also, clients can choose their own shipping agents. |
Import taxes: | We can help you reduce and avoid import tax by declaring price lower. |
